- Technical Details
-
- Commodity name: AFD2D-4L HHZ+Canopy
- Motor Power: 500W
- Battery: 48V 20Ah Lead Acid Batteries
- Tire: 300-10 tubeless
- Brake: F/R drum brake
- Speed: 3 Speeds 25KM/H Max.
- Max.Load: 150KG
- Cruising Range: 35-45 KM
- Wheel Base: 102CM
- Wheel Distance: 58CM
Product Size
Model: AFD2D-4L HHZ DP Climbing: 15° Size: 157*70*168CM Cruising Range: 35-45 KM Transmission: Gear box Speed: 3 Speeds 25KM/H Max. Wheel base: 102CM Brake system: F/R drum brake TIre size: 300-10 tubeless Braking distance: ≤5M Wheel distance: 58CM Controller: 12 tubes 60V Ground clearance: 11CM Rim: Alu.Alloy Voltage: 48V Charging time: 8H-12H Motor power: 500W Max. load: 150KG Battery: 48V 20Ah Lead Acid Batteries Gross weight: 168KG Suspension: F independent suspension
R spring shock absorber
Packing size: 165*73*110CM
